Product Name: 2 AA (Size 5) Battery Holder (with Lid, Switch, and Wires)
Appearance and Structural Features:
Overall Design: This is a fully enclosed black battery holder designed to hold two AA (Size 5) batteries. It features a pull-out lid that not only protects the internal batteries and circuitry but also makes it easy to replace batteries at any time.
Functional Features (Key Highlights):
Integrated Toggle Switch: A small toggle switch is located on the top of the battery holder (on the long side), clearly labeled with "ON" and "OFF" positions. Users can directly control the power on/off from the battery holder itself, eliminating the need for an additional switch in the external circuit.
Sliding Protective Lid: The battery compartment is equipped with a sliding black plastic lid with anti-slip texture for easy opening with fingers.
Materials and Manufacturing:
The exterior is made of high-quality black engineering plastic (usually ABS), which offers good insulation, wear resistance, and impact resistance. The surface has a matte finish.
Connection Method:
Red and black wires are led out from the back (red wire is positive, black wire is negative), with the ends already stripped. The images show the product's customization capabilities, as different lengths and specifications of wires can be provided according to customer requirements.
Mounting Design:
There is a round screw mounting hole at the bottom of the battery holder (near the wire ends), making it easy to securely attach the holder to a device's casing or panel.
Electrical Specifications:
The internal circuit is designed as a series connection, and two AA batteries can provide a DC output voltage of 3V.
Dimensions:
Length: 70mm
Width: 34.5mm
Height: 18mm
|
|
